SGPE-4000W Power Inverter High Frequency 12V/120V with USA Model FCC

It is our newly designed model, owns LED Intelligent digital display

it provides household power on the go!

It converts battery power DC 12V/24V/48VDC to AC 100/110/120/220/230/240V household power.

Product Specification:

Model	SGPE4000-121	SGPE4000-122	SGPE4000-241	SGPE4000-242	SGPE4000-481	SGPE4000-482
Rated Power	4000W
Surge Power	8000W(few seconds)
Input Voltage	12VDC		24VDC		48VDC
Output Voltage	110VAC±5%	220VAC±5%	110VAC±5%	220VAC±5%	110VAC±5%	220VAC±5%
USB Port	5VDC
Frequency	50Hz±3 or 60Hz±3
Output Waveform	Pure Sine Wave
Soft Start	YES
AC Regulation	THD<3%(Linear Load)
Output Efficiency	94% MAX
No Load Current	2.6A		1.3A		0.6A
DC Voltage Range	10-15.5V		20-31V		40-61V
Low Voltage Alarm	10.5±0.5V		21±0.5V		42±1V
Low Voltage Shut Down	10±0.5V		20±0.5V		40±1V
Low Voltage Recovery	13±0.5V		24±0.5V		48±1V
Over Voltage Shut Down	15.5±0.5V		31±0.5V		61±1V
Over Voltage Recovery	14.8V±0.5V		29V±0.5V		59V±1V
Cooling Way	Intelligent Cooling Fan
Protection	Battery Low Voltage & Over Voltage, Over Load, Over Temperature, Short Circuit
Working Temperature	-10ºC - +50ºC
Net Dimension	48.521.615.6cm (L×W×H)
Meas./Ctn	63.530.824cm/1pcs
N.W./Unit	10.5kg
G.W./Ctn	12.7KGS
Packing	Honeycomb carton
Warranty	2 Years
