Soft Start 230VAC 5V 1A Solar Panel Inverters 600W

    Buy cheap Soft Start 230VAC 5V 1A Solar Panel Inverters 600W from wholesalers

    Buy cheap Soft Start 230VAC 5V 1A Solar Panel Inverters 600W from wholesalers
    • Buy cheap Soft Start 230VAC 5V 1A Solar Panel Inverters 600W from wholesalers

    Soft Start 230VAC 5V 1A Solar Panel Inverters 600W

    Ask Lasest Price
    Brand Name : SUG
    Model Number : SGPR-600W
    Certification : CE & ROHS & FCC & PSE
    Price :
    Payment Terms : T/T, Western Union, Paypal
    Supply Ability : 7000pcs/month
    Delivery Time : Sample: 1-2days Bulk Order: 10-15days
    • Product Details
    • Company Profile

    Soft Start 230VAC 5V 1A Solar Panel Inverters 600W

    24V/220V High Quality Input Voltage Customization 600W Pure Sine Wave


    Company Profile:

    SUG is growing fast through years' great effort, now we have become one of the leading inverter manufacturer in China. We are working with reliable distributors with online & offline network throughout China. We look forward to expanding our business with new agent and customer for our mutual benefit with each other.


    FAQ:

    1.How can I store batteries?

    Do not locate batteries in place exposed to direct sun light, rain dust and adverse environments. Such exposure will cause damage to plastic components and may reduce battery life drastically. If the battery is not to be installed upon receipt, storage indoors is recommended. The batteries should be stored at a temperature of 15˚C-30˚C, in a clean, dry environment and provided with a freshening charge at intervals mentioned in point no.14. To prevent damage, do not stack wooden crates or battery packing cases one above the other,

    Luminous batteries have expected shelf life as indicated in the table below . During the storage interval (i.e. between date of shipment and date of installation),For batteries stored at 270C, a freshening charge should be given once in every six(6) months. Storage at elevated temperatures will result in accelerated self-discharge as indicated below.

    Temp in ˚CStorage interval in months
    Up to 275.0
    27-323.5
    32-373.0
    37-422.2

    Storage beyond these periods without charge will result in excessive sulphation of plates and degrade battery performance and life.

    Products Specification:


    ModelSGPR600-121SGPR600-122SGPR600-241SGPR600-242SGPR600-481SGPR600-482
    Rated Power600W
    Surge Power1200W(few seconds)
    Input Voltage12VDC24VDC48VDC
    Output Voltage110VAC±5%220VAC±5%110VAC±5%220VAC±5%110VAC±5%220VAC±5%
    USB Port5V 0.5A
    Frequency50Hz±3 or 60Hz±3
    Output WaveformPure Sine Wave
    Soft StartYES
    AC RegulationTHD<3%(Linear Load)
    Output Efficiency94% MAX
    No Load Current0.6A0.3A0.1A
    DC Voltage Range10-15.5V20-31V40-61V
    Low Voltage Alarm10.5±0.5V21±0.5V42±1V
    Low Voltage Shut Down10±0.5V20±0.5V40±1V
    Low Voltage Recovery13±0.5V24±0.5V48±1V
    Over Voltage Shut Down15.5±0.5V31±0.5V61±1V
    Over Voltage Recovery14.8V±0.5V29V±0.5V59V±1V
    Cooling WayIntelligent Cooling Fan
    ProtectionBattery Low Voltage & Over Voltage, Over Load, Over Temperature, Short Circuit
    Working Temperature-10ºC - +50ºC
    Net Dimension20.2*15*8cm (L×W×H)
    Meas./Ctn63*34*38.5cm / 10pcs
    N.W./Unit2.0KG
    G.W./Ctn24KGS
    Packingbox
    Warranty2 Years

    Inverter Display:
